Three-Way & Four-Way Ball Valves – L/T Port, Diverter & Mixing

Nominal Size： DN25 (1 inch); range DN15 to DN100
Pressure Rating： PN16 (16 bar); PN10, PN25, PN40 available
Port Pattern： L-port diverter or T-port mixing
Rotation： 90 degrees for L-port; 180 degrees with four position stops for T-port
Body Material： ASTM A216 WCB, A351 CF8 (304), A351 CF8M (316)
Ball： 304 / 316 stainless, hard chrome plated option
Stem：316 stainless, anti-blowout, anti-galling treatment
Seat： PTFE, RPTFE, PPL; metal seat optional
Kvs DN25 L-port： about 30 m3/h
Kvs DN25 T-port： about 22 m3/h
Break Torque DN25： 18 to 28 N·m L-port; 22 to 32 N·m T-port at PN16
End Connection： Flanged EN 1092-1 PN16, threaded G / NPT, socket weld, butt weld
Face to Face： 130 mm to EN 558 series 1 for DN25 flanged
Design Standard： API 608, EN 12516, ASME B16.34 as applicable
Test Standard： API 598, EN 12266-1
Temperature Range： -29 to 180 degrees C with PTFE; to 250 with PPL
Operation： Lever, worm gear, pneumatic 90 or 180 degree, electric

A three way floating stainless steel threaded ball valve with ISO 5211 mounting pad for direct actuation. 1000 PSI WOG, full bore, L port and T port patterns in SS316 and SS304, factory direct from J-VALVES.

Size Range： DN15 to DN200 (1/2 to 8 inch)
Pressure Class： ASME Class 150 to 600 / PN20 to PN100
Port Configuration： 3 port with L or T port ball, 4 port with X port ball
Seat Count： 2 seats or 4 seats
Body Material： WCB, CF8M, CF3M, A105
Ball： CF8M / F316, hard chrome or ENP plated
Seat Material： RPTFE, PTFE, PEEK, or metal seated
Stem： F316 or 17-4PH, blow-out proof, anti-static
End Connection： Flanged RF/RTJ to B16.5, butt weld to B16.25, socket weld
Design Standard： API 6D, API 608, ASME B16.34
Pressure Test： Shell 1.5x, seat 1.1x, API 598
Cavity Relief： Drilled relief hole in ball or self-relieving seat
Operation： Lever, gear, pneumatic or electric, 90 or 180 degree

A 3 inch PN20 three-way stainless floating ball valve in CF3M, with an L port for diverting or a T port for mixing and splitting, PTFE seat and RF flanges to ASME B16.5.

Nominal Size: DN25 (1″)
Pressure Rating: PN16 (1.6MPa)
Body Material: WCB Carbon Steel / CF8 (304 Stainless Steel) / CF8M (316 Stainless Steel) / CF3M (316L Stainless Steel)
Temperature Range: -29℃ to +425℃
Body / Side Body: WCB / CF8 / CF8M / CF3M
Ball: CF8 / CF8M / CF3M, with optional polished surface (for hygienic applications)
Stem: 304 / 316 / 316L Stainless Steel
Seat: PTFE / RPTFE / PPL / Metal Seal (optional)
Packing: PTFE V-rings / Flexible Graphite
Bolts: A2-70 (stainless steel) / B7 (for carbon steel valves)
Nuts: A2-70 / 2H
End Connection: Flanged (RF), conforming to EN 1092-1 PN16; threaded (NPT/BSPT), welded (BW/SW) or three-piece clamp connection available as options
Flange Face Dimensions: Conforms to EN 1092-1 Type 01 (plate type). For DN25 PN16 flange: outer diameter 115mm, bolt circle diameter 85mm, bolt hole diameter 14mm, 4×M12 bolts, flange thickness 16mm, raised face diameter 68mm
Face-to-Face Dimension: Approx. 102mm (three-piece design, conforming to EN 558 or manufacturer’s standard)
Operation: Manual (lever / worm gear), pneumatic (double-acting / single-acting), electric (on-off / modulating)
Design Standard: API 608
Test Standard: API 598

Nominal Diameter: 4 inches (DN100)
Pressure Class: Approx. 1.6 MPa (PN16)
Temperature Range: -29℃ to +425℃
Flow Pattern: L-port (90° diversion) or T-port (splitting / mixing / 180° diversion)
Valve Body / Bonnet / Center Section: ASTM A351 CF8 cast stainless steel (equivalent to 304)
Ball: CF8 / 304 with hard chrome plating, or CF8M (optional)
Stem: 304 or 316 stainless steel
Seat: PTFE, RPTFE, PPL (reinforced PTFe); PEEK is available for clean service conditions
Sealing Materials: PTFE / RPTFE / PPL (seat seals), flexible graphite or PTFE (stem packing)
End Connection: Flanged (RF raised face, conforming to EN 1092-1 / GB/T 9113)
Operation: Pneumatic (double-acting or spring return)
Air Supply Pressure: 0.4–0.7 MPa (standard); high or low pressure versions available on request
Accessory Options: Solenoid valve, limit switch, positioner, filter regulator, handwheel mechanism, quick exhaust valve, etc.
Design Standard: ASME B16.34, API 608
Inspection & Test Standard: API 598
Face-to-Face Dimension: In accordance with ASME B16.10

Nominal Size: 3" (DN80)
Pressure Class: 150LB (PN20)
Temperature Range: -29℃ to +425℃
Flow Pattern: L-port (90° diversion) or T-port (splitting / mixing / 180° switching)
Body / Bonnet / Center Section: Cast stainless steel ASTM A351 CF3M (equivalent to 316L)
Ball: CF3M / 316L with hard chrome plating, or CF8M (optional)
Stem: 316L or 316 stainless steel
Seat: PTFE, RPTFE, PPL (reinforced PTFE); PEEK available for hygienic service
Sealing Materials: PTFE / RPTFE / PPL (seat), flexible graphite or PTFE (stem packing)
End Connection: Flanged (RF Raised Face, conforming to ASME B16.5)
Operation: Manual (lever / worm gear), pneumatic, electric, hydraulic (direct mounting with ISO 5211 standard high platform interface)
High Platform Standard: ISO 5211 F07 / F10 / F12, etc. (matched to actuator torque)
Optional Accessories: Solenoid valve, limit switch, positioner, filter regulator, etc.
Design Standards: ASME B16.34, API 608
Testing Standard: API 598
Face-to-Face Dimension: Conforms to ASME B16.10

Nominal Size: 1″ (DN25)
Pressure Class: 150LB (PN16)
Temperature Range: -29℃ to +425℃
Body / Bonnet: WCB (carbon steel, economical); CF8 (304 stainless steel, general corrosion resistance); CF8M (316 stainless steel, chloride corrosion resistance)
Ball: Solid WCB / CF8 / CF8M, or with ENP (electroless nickel plating) / hard chrome surface treatment
Stem: CF8 / CF8M, SUS304 / SUS316, or 2Cr13 stainless steel
Seat Sealing: PTFE (-20℃~150℃); RPTFE (glass fiber reinforced PTFE, -20℃~180℃); PPL (polyphenylene, -29℃~280℃)
Packing: PTFE V-rings or flexible graphite
Gasket: Flexible graphite stainless steel spiral wound gasket or PTFE envelope gasket
Bolts: SUS304 / SUS316 stainless steel or ASTM A193 B7 (zinc plated)
End Connection: Flanged (RF Raised Face, EN 1092-1 PN16 / GB/T 9113 PN16); optional NPT female thread, SW socket weld or BW butt weld ends
Operation: Manual (lever with locking hole); optional pneumatic (single/double acting) or electric actuator
Design Standards: API 608, ASME B16.34, GB/T 12237
Testing Standards: API 598, GB/T 13927
Face-to-Face Dimension: In accordance with GB/T 12221

Size Range: 1/2″ to 8″ (DN15 to DN200)
Pressure Class: 150LB to 600LB (PN20 to PN100)
Temperature Range: -29℃ to +425℃
Body / End Caps: ASTM A216 WCB (carbon steel), A351 CF8/CF8M (stainless steel), A105 (forged steel)
Ball: WCB/CF8 with ENP (electroless nickel plating) / hard chrome plating / stainless steel hardfacing
Stem: 17-4PH precipitation-hardening stainless steel, A105+ENP, SUS316
Seat Seal:PTFE (-29℃ ~ 150℃).RPTFE (-29℃ ~ 180℃).PPL (-29℃ ~ 280℃)
Metal seal with flexible graphite (-29℃ ~ 425℃)
Packing: PTFE V-rings or flexible graphite
Gasket: Flexible graphite stainless steel spiral wound gasket or rubber gasket
Bolts: ASTM A193 B7/B8M, matched with A194 2H/8M nuts
End Connection: Flanged (RF/RTJ), threaded (NPT/BSPT), butt-weld (BW)
Operation: Pneumatic (single-acting spring return / double-acting, standard); optional electric, hydraulic or manual gearbox for backup
Air Supply Pressure: 0.4~0.7 MPa (standard), customized air supply available upon request
Switching Time: Adjustable from 0.5 to 5 seconds (depending on size and torque)
Design Standards: ASME B16.34, API 608, API 6D
Testing Standard: API 598
Face-to-Face Dimensions: In accordance with ASME B16.10

Nominal Diameter: DN100 (4 inches)
Pressure Class: PN16 (1.6 MPa)
Temperature Range: -29℃ to +425℃
Body: ASTM A351 CF8 (304) stainless steel
Ball: CF8 / CF8M (304 / 316) stainless steel, with optional polished surface finish
Stem: 304 / 316 stainless steel
Seat: PTFE, RPTFE, PPL, metal seat (Stellite hardfacing, optional)
Packing: PTFE / Flexible graphite / Braided graphite
Flange Face: RF (Raised Face), conforming to EN 1092-1 / DIN 2501
End Connection: Flanged (RF, in accordance with EN 1092-1 / DIN standards)
Operation: Pneumatic (standard), with optional manual override mechanism
Type: Double-acting / Single-acting (spring return)
Air Supply Pressure: 0.4~0.7 MPa (4~7 bar)
Port Threads: G 1/4" / NPT 1/4"
Stroke: 90° rotary
Actuating Time: 2~5 seconds (depending on actuator size and air supply pressure)
Optional Accessories: Solenoid valve, limit switch, positioner (4~20 mA), filter regulator, speed control valve
Design Standard: GB/T 12237, API 608
Test Standard: GB/T 13927, API 598
Face-to-Face Dimension: In accordance with ASME B16.10

Nominal Diameter: 3" (DN80)
Pressure Rating: 150LB (PN20)
Temperature Range: -29℃ to +425℃
Body: ASTM A351 CF8M (316) stainless steel
Ball: CF8M / CF3M (316 / 316L) stainless steel, with optional polished surface finish
Stem: 316 / 316L stainless steel
Seat: PTFE, RPTFE, PPL, metal seat with Stellite alloy overlay (optional)
Packing: PTFE / flexible graphite / braided graphite
Flange Facing: RF (Raised Face), conforming to ASME B16.5
End Connection: Flanged (RF, conforming to ASME B16.5)
Operation: Manual (lever handle, standard); high mounting platform for direct mounting of pneumatic / electric / hydraulic actuators
Mounting Height: 50~150 mm higher than standard ball valves (depending on specific design)
ISO 5211 Mounting Flange: F07~F16 available to match different actuator torque ratings
Actuator Compatibility: Direct mounting of rack-and-pinion and scotch-yoke pneumatic actuators, multi-turn electric actuators without adapter brackets
Design Standard: ASME B16.34, API 608
Inspection Standard: API 598
Face-to-Face Dimension: Conforms to ASME B16.10

Nominal Diameter: DN100 (4")
Pressure Class: PN16 (1.6 MPa)
Temperature Range: -29℃ to +425℃
Body: ASTM A351 CF8 (304) Stainless Steel
Ball: CF8 / CF8M (304 / 316) Stainless Steel, with optional polished surface finish
Stem: 304 / 316 Stainless Steel
Seat: PTFE, RPTFE, PPL, metal seal (Stellite hardfacing, optional)
Packing: PTFE / Flexible Graphite / Braided Graphite
Flange Face: RF (Raised Face), conforming to EN 1092-1 / DIN 2501
End Connection: Flanged (RF), in accordance with EN 1092-1 / DIN standards
Operation: Pneumatic (standard)
Type: Double-acting / Single-acting (spring return)
Air Supply Pressure: 0.4~0.7 MPa (4~7 bar)
Port Thread: G 1/4" / NPT 1/4"
Stroke: 90° rotary
Switching Time: 2~5 seconds (depending on actuator size and air supply pressure)
Accessory Options: Solenoid valve, limit switch, positioner (4~20 mA), filter regulator, speed control valve
Design Standard: API 608
Inspection Standard: API 598
Face-to-Face Dimension: ASME B16.10
