API600 Flange Gate Valve, 300LB 6'', this is an order of stainless steel gate valve, deliver to America market.

We produce gate valve from 1/2''-48'', pressure 150LB~2500LB/PN16~PN260, material mainly have stainless steel, carbon steel, alloy steel according to API, DIN, JIS, GB/HG standards to meet different markets.

Generally speaking for stainless steel material, will not painting, but this order is special, because end user want to use silver grey for it, it is easy to identify on site when install and use.

API600 gate valve, we strictly inspect casting raw materials, for example before process, we need to check its surface, dimension, thickness, sand holes, etc., which should totally according to API600 standards. We also need to check its dimensions during every process. After finishing process, before assembly every parts need do shot-blasting and cleaning.

After aseembly, our inspector make pressure testing for each valve, also need to inspect dimensions and quality.

What we do, only want to ensure quality for each valve, to make clients satisfied with our products.

Welcome to inquiry us.


API600 stainless steel flange gate valve
