This week we are glad to export an order about forged steel F304 lift check valve to Mexico for Oil pipeline.

Generally speaking, check valve has many different types, such as swing type, lift type, y type, etc. But in forged steel, lift type is mostly used in oil industry. Check valve as one way type, can not control by handle, it operates automatically by spring in it.

For forged steel check valve, we could produce in NPT, BSPP, BSPT threaded ends, or could customize according to client's requirements.  And we have many materials are available here, such as F304/F316/F304L/F316L, A105, F11, F55, F51, F91, LF2, F321, etc. Pressure from 150LB to 2500LB in threaded/welded/flanged ends.

Thanks for customers' trust and support, we will keeping improving always.


stainless steel F304 check valve
