Screwed Ball Valves:
Maximum working Pressure 3000lbs (3000PSi), Body: Forged Carbon Steel, ASTM A105, Gland. Packing: PTFE/Teflon, Conn: NPT Screwed (Female), Operation: Lever/Wheel, Trim Material: Stainless Steel, Stem: Stainless Steel, Max Temp: 290°F.

1) 2" dia Full Bore Ball Valve, Ball: Forged Steel ASTM A 105 with 0.0003"   Electroless Nickel Plating.

2) 1/2" dia Full Bore Ball Valve, Ball: Forged Steel ASTM A105 with 0.0003" Electroless Nickel Plating.


Screwed Ball Valve : 2" Ø Full Bore Ball Valve, 3000 lb.

Screwed Ball Valve : 1/2" Ø Full Bore Ball Valve, 3000 lb.


Hope you are enjoying good health and nice mood. One of our valued client is interested to buy “Screwed Ball Valve“



Details Technical specification & price schedule is attached.



Therefore, you are requested to send us your best offer in RMB conforming following terms.



Terms

1.       Offer Validity: 90 days from the date of 18 September 2017.

2.       Delivery: Within 30 days after receipt of order.

3.       Payment: 30% advance and rest before delivery but after complete the Inspection. All payment currency will be RMB. You shall have to issue sales tax invoice to receive all payment. Your scope of work is production, packing, your factory Test and delivery up to Tianjin Sea Port warehouse.

4.       Pre-Shipment Inspection:  It will be carried out by third party inspection company by buyer cost.

5.       Packing : Seaworthy extra strong export standard wooden box packing.



Please included following with the offer:

1.      Manufacturer catalogue/brochure for quoted all items (Send us PDF version)

2.      Manufacturer’s Valid certificates of : ISO 9001 / ISO 9002.



If you have any questions please do not hesitate to ask me.


forged steel flange ball valvestainless forged steel flange full bore ball valvestainless forged steel flange full bore A105 ball valve
