Home API608 Carbon Steel Flange Floating 150LB Ball Valve Export to Chile Customer
Publish Time: 2020-10-27
Views: 1
Author: Site Editor
Origin:
Website:
Inquire

Really thanks for our client's support to ship this order of Flange Ball Valve in A216 WCB, 150LB, floating type, with lever operated.

Flange floating ball valve is suitable for normal pressure pipeline, it could use casting steel material, as well as forged steel material. Generally speaking, most forged steel materials are used in high pressure pipeline. But for flange ball valve, if working condition need high pressure, suggest install trunnion mounted ball valve, it is more stable and reliable.

Flange floating ball valve, has soft seat, such as PTFE, RPTFE, PPL, PEEL; also has metal seat for high temperature or corrosive mediums.

Flange floating ball valve had fire safe design to avoid some dangerous using in pipeline. It is a big advantage than other types valves.

Flange floating ball valve is widely used in different industries to meet different requirements.

Welcome to your inquiry if need.


flange ball valveWCB API 150LB flange ball valve
