Pneumatic Stainless Steel L/T Port Flange Three Way Ball Valve

Pneumatic Stainless Steel L/T Port Flange Three Way Ball Valve

Structural Features

• High-Quality Stainless Steel Material: The valve body, ball, and stem are all made of 304 or 316 stainless steel, featuring high strength and good corrosion resistance. They can resist erosion from various chemical media, extending the valve's service life.

• L-shaped and T-shaped Port Designs: The L-shaped port design is used to connect one inlet to one of two outlets, suitable for simple diverting operations; the T-shaped port design can achieve more complex fluid control, including diverting, mixing, or isolating fluids.

• Pneumatic Actuator: Equipped with a double-acting or single-acting pneumatic actuator for fast remote control and automated operation. The actuator offers various options, such as solenoid valves, limit switch boxes, filters, and E/P positioners, to meet different control requirements.

• ISO 5211 Mounting Interface: The valve is designed in compliance with ISO 5211 standards, facilitating the installation and replacement of actuators, and improving system compatibility and maintenance convenience.

• Fire-Safe Design: Complies with API 607 standards. Even in fire conditions, the valve can maintain sealing performance, preventing medium leakage and ensuring system safety.

• Anti-Static Device: Built-in anti-static device effectively prevents static accumulation, reducing the risk of fire and explosion, and is particularly suitable for controlling flammable and explosive media.

• Compact Design: Small in size and light in weight, it is easy to install and integrate into existing systems, saving space.

Technical Parameters

• Size Range: DN15 (1/2″) to DN150 (6″)

• Pressure Rating: PN16, PN25, 150LB, 300LB, JIS 10K, JIS 20K

• Temperature Range: -20℃ to +200℃ (the specific range depends on sealing materials and working conditions)

• Materials:

• Valve Body: 304, 316 stainless steel

• Ball: 316 stainless steel

• Stem: 316 stainless steel

• Sealing Material: PTFE, RPTFE

• Connection Type: Flange connection (ASME B16.5)

• Operation Mode: Pneumatic (single-acting or double-acting)

• Design Standards: API 608, ASME B16.34

• Testing Standards: API 598, EN 12266

Application Scenarios

• Oil and Gas Industry: Used in oil and gas field exploration, gathering, transportation, and processing systems to ensure reliable isolation and control of media.

• Chemical Industry: Suitable for conveying and reaction systems of various chemical media, preventing medium leakage and ensuring production safety.

• Pharmaceutical Industry: Applied in pipeline systems during pharmaceutical production to ensure media isolation and cleanliness in the drug manufacturing process.

• Food and Beverage Industry: Meets food-grade requirements, used in pipeline systems for food and beverage production to ensure hygiene and safety.

• HVAC: Utilized in cooling water systems, hot water systems, etc., to ensure efficient operation of the system.

• General Industrial Use: Suitable for controlling and isolating media such as water, oil, and gas.

Advantages and Value

• High Reliability: The stainless steel material and floating ball design ensure stable operation under high pressure and temperature, reducing maintenance frequency and downtime.

• High Safety: Fire-resistant and anti-static designs, along with reliable sealing performance, effectively reduce leakage risks and protect personnel and equipment.

• Automated Operation: Equipped with a pneumatic actuator to realize remote control and automated operation, improving system flexibility and safety.

• Easy Installation and Maintenance: Flange connections simplify the installation process and facilitate maintenance and repairs.

• Wide Applicability: Multiple material options and a broad range of pressure and temperature ratings allow it to adapt to various complex working conditions and media characteristics.
