Forged Stainless Steel Threaded/Welding Globe Valve(150LB~2500LB)

Forged Stainless Steel Threaded/Welding Globe Valve(150LB~2500LB)

Forged Stainless Steel Globe Valve specifications:

1. Size: 1/2’’~2’’(DN15~DN50)

2. Pressure: 800LB~2500LB

3. Material: A182-F304/316/304L/316L, A105,F11,F22,F51,LF2, etc.

4. Ends: NPT, BSPP, BSPT, Socket Welded

5. Port: Reduce Port

6. Seal/Seat: Metal

7. Working temperature: ~196℃ to 525℃

Forged Stainless Steel Globe Valve features:

1. Outside Screw and Yoke (OS&Y)

2. Self aligning two piece packing gland

3. Spiral-wound gasket

4. Integral backseat

Forged Stainless Steel Globe Valve features:

1. Design & manufacturer standard: API 602 & ANSI B16.34

2. Face to Face dimension standard: ANSI B16.10

3. Socket Weld Ends standard: ASME B16.11

4. Screwed Ends (NPT) standard: ASME B1.20.1

5. Butt Welding Ends standard: ASME B16.25

6. Test and Inspect standard: API 598

Forged Stainless Steel Globe Valve, has three design for bonnet,one is bolted bonnet, use stainless steel and flexible graphite spiral wound gasket. One is welded bonnet, welding it after sealed by thread. The last one is pressure sealed bonnet, connected by thread and pressure sealed bonnet. Forged Stainless Steel Globe Valve, through the pressure of stem, make disc sealing surface and seat sealing surface closely fit to prevent medium from flowing. Forged Stainless Steel Globe Valve, is single direction flow valve, when installation, it has its own direction on valve body. Globe valve length is longer than gate valve, and the fluid resistance is stronger than gate valve, for long-term operation, the reliability of sealing is not good as gate valve.

Forged Stainless Steel Globe Valve competitive advantages:

1. Our products is guaranteed within 18 months after delivery.

2. We offer free sample if interest before orders.

3. Technology renovation, process improvement, structure optimization and quality improvement.

4. Excellent after-sales service system, providing timely and optimal service, which help you to win the market.

5. Convenient shipping sea port, and standard exporting carton boxes & plywood cases.

6. 100% inspection & testing before delivery.

7. Third party inspection on customer requirement.
