Stainless Steel CF8 CF8M ASME B16.5 Flange Ends Gate Valve

Stainless Steel Flange Ends Gate Valve

1.  Wedge gate valve, solid wedge and flexible wedge.

2. Class 150LB~2500LB pressure, size 1/2''~36''.

3. Stainless steel, alloy steel, nickel steel, duplex steel , low temperature steel, etc.

4. Gate valve has two sealing face in one wedge, wedge open and close fully to control medium, full bore.

5. Gate valve wedge could overlay alloy steel like stellite to reinforce hardness.

6. Gate valve stem will do thermal refining and nitrogen treatment, which make good corrosion resistance, abrasion resistance and wear resistance.

7. Can be used with a variety of standard pipe flanges and flange sealing surface types to meet various project needs and user requirements.

8. Handwheel operated and gearbox operated and actuators operated.

9. API, JIS, EN, ASME, GOST, GB standards.

Stainless Steel Gate Valve specifications:

1. Size: 1/2’’~48’’(DN15~DN1200)

2. Pressure: 150LB~2500LB

3. Material:WCB, WCC, LCB,LCC,WC6,WC9, C5,C12, etc.

4. Ends: RF. RTJ, FF, BW, etc.

5. Port: Full Port

6. Working Temperature: -196~425℃, or according to customer requirements for different industry.

7. Operating: Gearwheel, Pneumatic actuator, Electric actuator.

Stainless Steel Gate Valve applicable standards:

1. Design & Manufacture standard: API 600

2. Pressure & Temperature standard: ASME B16.34

3. Face to face dimension standard: ASME B16.10

4. Flange standard: ASME B 16.5, ASME B16.47

5. Test & Inspect standard: API 598

Stainless Steel Gate Valve features:

1. Outside Screw and Yoke

2. Bolted Bonnet and Pressure Seal

3. Flexible and solid wedge, fully guided

4. Welding seat rings or Renewable seat rings

5. Rising stem and non-rising stem

6. Available with gear operator

7. Flange Ends & Butt welding Ends

8. Low torque design, smooth surface stem.

Stainless Steel Gate Valve competitive advantages:

1. Our products is guaranteed within 18 months after delivery.

2. We offer free sample if interest before orders.

3. Technology renovation, process improvement, structure optimization and quality improvement.

4. Excellent after-sales service system, providing timely and optimal service, which help you to win the market.

5. Convenient shipping sea port, and standard exporting carton boxes & plywood cases.

6. 100% inspection & testing before delivery.

7. Third party inspection on customer requirement.
